31 Mar Microfluidic quantification of bacterial single-cell motility can be used as a proxy for bacterial heteroresistance
One of the most promising applications of microfluidics technology has been proven to be the single-cell analysis. Hardly a week goes by without a new microfluidic development for microfluidic single-cell analysis. Over the nearly past decade, the field has accelerated at a high rate and continued to facilitate single-cell analysis for genomics, transcriptomics, proteomics, etc. for researchers. A recent publication in Nature Communications reports a novel advancement for microfluidic single-cell analysis.
A Zurich-based research group takes advantage of the combination of a microfluidic chip with open microchannels and acoustic manipulation for 3D mechanical characterization of single-cells and small organisms.
“Here, we combine an acoustically driven manipulation device with a micro-force sensor to freely rotate biological samples and quantify mechanical properties at multiple regions of interest within a specimen. The versatility of this tool is demonstrated through the analysis of single Lilium longiflorum pollen grains, in combination with numerical simulations, and individual Caenorhabditis elegans nematodes.”, the authors explained.
The open microfluidic device was made from PDMS using conventional microfluidic microfabrication methods. The open microchannel contained a linear array of rectangular microcavities which were used to trap microbubbles. The hydrophobic/hydrophilic interaction caused the locally confined microbubbles to stay trapped inside the microcavities during the experiment. The specimen was then introduced to the microchannel and positioned near the microbubbles. A piezo transducer placed near the microfluidic device excited the microbubbles resulting in the formation of microvortices near the microbubble and in the surrounding liquid as shown in the image. These microvortices exerted force on the specimen and resulted in rotation of the specimen.
Microchannels can guide the axons and promote controlled directional growth. The microfluidic channel dimensions can impact the growth of the axons and were thus optimized in this study for robust isolation of axons of hPSC-derived neurons. The surface of the microfluidic chips was functionalized with a photo-responsive material containing the azobenzene. The surface of the microchannel could reversibly change in response to the light irradiation and thus could be used for modulating the axonal growth and alignment in the desired direction.
“In this study, we showed that successful isolation of axons from somas and dendrites combined with the robust axonal outgrowth of hPSC-derived and rat primary cortical neurons in a compartmentalized microfluidic PDMS device is greatly influenced by the cross-sectional area and the length of the separating microtunnels. Furthermore, we created an hPSC-derived neuron-based axonal model consisting of a compartmentalized PDMS microtunnel chip integrated with photoinscribed nanotopography on light-responsive, azobenzene-based molecular glass.”, the authors concluded.
